Brand Name : | SINOWELL |
Model Number : | VK20045 |
Certification : | RoHs; CE |
Price : | $0.2/pc--$1.9/pc |
Payment Terms : | D/P; T/T; Western Union |
Supply Ability : | 10000pcs per day |
Delivery Time : | Depend on your quantity |
Straight N Male To BNC Female Adapter With Copper Pin / Zinc Alloy Body
Specifications:
BNC MALE TO N MALE
Material: Copper Pin and Zinc Alloy Body
Description:
Temperature Range | -55~+155℃(PE Cable -40~+85) | |
Vibration | 100m/S2 (10-2000Hz). | |
Impedance | 50Ω | |
Frequency Range | DC ~to 1.24GHz (Semi-Rigled Cable DC-18GHZ | |
Working Voltage | 335V r.m.s at sea level | |
Withstanding Voltage | 1000V r.m.s at sea level | |
Contact Resistance | Center contact | ≤3m Ω |
Outer contact | ≤2.5m Ω | |
Insertion Loss | ≤0.24dB(6GHz) | |
Insulation resistance | ≥5000M Ω | |
Center Conductor Retention Force | ≥0.28N | |
Voltage Standing Wave Ratio | Straight | ≤ 1.10+0.02f |
Right angle | ≤ 1.20+0.03f | |
Durability(mating) | ≤500cycles | |
Body | Brass, Gold plating | |
Contact | Beryllium copper, Gold plating | |
Insulator | PTFE |
1) Packed in polybag/tray ,and cartons (bulk package )
2) Private packing and label service are available as per your requirement
Competitive Advantage:
Applications:
RF
Shipping Details:
1. The parts from us are sure to have quality warranty, and they are double tested before shipping.
2. The items can be sent within 7-10 working days after we received the payments.
3. As for mass production, we will confirm the delivery in advance.We will send you’re the products by UPS/DHL/TNT/ FedEx.
![]() |
